Tijian Liulin Bridge

Location： China/Tianjin

Area：None

Design time：2005.06

Owner： Tianjin HaiHe River Construction Development Inves

Project Type： Public Building



Introduction: Powerful of ring shape closed beam are set near the steel. Above beam part, cold cast is set anchoring oblique zip, deck following oval steel beams in and internal concrete main beams received parts preset shear force nail; edge across using steel-concrete stack hop beam, steel beams for longitudinal-beam system, top surface set welding nail, and deck wet connector effective connect overall; Tower column using arch, tower to Strait tilt to weight balance zip to direction of rally.
